real extruded enclosure

a)Material:T6063 in general;

b)Color:Silver;

c)Surface treatment:Anodize;

d)Protection Class:

IP53/ EMC;

e)With front/rear panels;

f)With mounting bracket.

S/N

Part Name

QTY

Meterial

Sepcifcation

1

Body-1

1

T6063

Finished

Mat

2

Body-2

1

T6063

Weight

3

F.Panel

1

T6063

Package

50/C

4

R.Panel

1

T6063

5

Screw

8

Steel

- Color and material(T6061-T6066,different hardness) can be customized;

- Surface treatment can be customized such as anodize/sand blast anodize/wire drawing anodize;

- Front and rear panel of enclosures can be customized to meet the exact requirements of a customer's application such as drilling holes/adding mounting bracket and so on;

- We can provide silkscreen service according to your drawings;

- Drawings from website was just for reference, More correct information and some special requirements, please kindly contact us;

- MOQ : 500 PCS;

- Price terms : FOB NingBo or ShangHai;

- Payments terms : By T/T advanced in general;

- Lead-time : 3 weeks after T/T;
